Viewing I: the wonders of perspective

CS 248 - Introduction to Computer Graphics
Autumn Quarter, 1999
Marc Levoy
Lecture notes for Thursday, November 4

Table of contents:

If you want to play with the program I used in class to demonstrate:

then log on to a Sweet Hall SGI and type:
/usr/class/cs248/support/bin/iris4d/frustum /usr/class/cs248/data/Inventor/spheres.iv

Press here for a brief history of the invention of perspective.

Press here for a discussion of problems on the use of perspective in art.
Copyright © 1999 Marc Levoy
Last update: November 9, 1999 02:44:56 AM
