Lost at Sea

CS348B Final Project

Dmitry Belogolovsky & Woodley Packard

Our presentation can be found here.
Our short movie can be found here.

Introduction

Our goal was to render an electric storm striking an ocean. We both took several years of ancient Greek in high school, so we decided to theme the picture along those lines; they scene is supposed to represent a Greek ship lost on its way to battle. Here are a couple of lightning photographs that we found inspirational while working on the project:

The image consists of several fairly independent components:

Sky

• Experiments

We explored several types of sky.
• 2D-photon mapping
• heightfield-based geometry
• flat procedural texturing
• metaballs

Here are some sample images from our experimental sky techniques:  Flat Texture Pure Volume Metaballs Volume Heightfield
• Final Sky

We decided to go with the final approach of 3D-photon mapping [1]. The water reflects the sky, and so finding a physically-accurate model for the sky required a lot of attention. Although some of the other methods looked pretty good, volume rendering the 3D photon map added the most realism to the scene. The density function for the sky is 3D Perlin noise.

We traced 10 million photons through the volume of the clouds to generate a volumetric photon map. For space-efficiency and access time, we stored the resulting data as a 3D texture map. This optimization circumvented the costly search operation.

Next, we used Peter Williams' "Volume Density Optical Model" [2] to render the photon map as a luminous volume. The photon map saved us the work of recursively tracing shadow and scatter rays from our primary ray-march, converting the exponential general-case volume rendering integration into a linear time algorithm.

 A slice of the 3D photon map The resulting image

Ocean

The ocean in our scene is a procedural heightfield. The altitude as a function of the projected planar position is calculated as a sum of sinudoidal wave patterns with varying frequencies and amplitudes. We used two types of waves:
• Linear waves: The lines of curvature are orthogonal and straight. There are globally two principal directions. These monotonic waves are the sort that a steady wind will cause.
• Circular waves: The lines of curvature are still orthogonal, but are not all straight. The first set of lines of curvature form concentric circles around a given point, while the second set are radial spokes from that point. This kind of waves occur in nature due to specific events (for example, when a large fish makes a splash).
The technique is the one described by M. Finch [6]. We found that if we only used one type of waves, the water looked nice locally but had obvious repeating patterns globally. Using the two techniques in tandem made the ocean look much more dynamic.

The ocean is raytraced using Musgrave's QAEB-tracing algorithm [5]. Precise procedural normals are available from the underlying analytically defined surface. Reflection rays are generated upon collision, and weighted by a function of their incident angle. We did not trace any rays underwater, but we did use an approximation to the subsurface scattering caused by the bright lightning:

 No Subsurface Scattering With Subsurface Scattering

Since the water is defined by simple wave functions, it was possible to accurately solve the governing partial differential equations for its motion. Using d'Alembert's solution to the wave equation [7], we animated the water in a physically accurate fashion without having to numerically solve PDEs.

Lightning

• Geometry

We used a stochastic process to simulate a realistic lightning geometry as a phenomenological model. The program steps through the lightning in a random direction, determined by parameters to a recurive function, rotates a random amount, and branches a random distance. We control all the randomness with constraints and heuristics. For example, the lightning branches less at the top and more towards the end. To add curvature to the lightning, we used sin waves with constrained random parameters. Additional measures were taken to force the main branch to always reach the surface of the water. As output, the lightning geometry generation program exports line segments. The line segments can either feed into our Modeling Studio or into the raytracer program.

Although the geometries tend to look fine with no tweaking, we also decided to implement a Lightning Modeling Studio GUI to perfect the geometries before rendering. We implemented the Lightning Studio in YZ-Windows.

To get a sense of the temporal aspects of lightning storms, we watched a couple of videos of lightning (from wvlightning.com) and noticed that the geometries repeated for several seconds. We thus decided to use the same geometry for multiple flashes in our short video. Here is a lightning scientist's explanation of this effect:

In lightning science vocabulary, lightning is broken down into several parts. The initial downward discharge is called a "leader". The "return stroke" that completes the electrical current is the bright, visual channel that we see. Several return strokes can move up and down this channel many times, creating the "flickering" effect. This entire event may last half a second and is called a "flash". Outside the lightning science community, most people commonly refer to the entire, half-second lightning event as a "strike" or "bolt". [8]
• Rendering

The lightning is rendered as a linear light source. Since it has negligable thickness, rays cannot collide with it, so to make it visible to the viewer, we had to render the entire atmosphere as a (very low-density) volume. Atmospheric particles near the lightning reflect a large amount of light to the viewer, while particles distant from the lightning reflect little light. This produces the glowing visual effect for the lightning (in particular, the glow was NOT done as an image-space operation or camera effect). Since we wanted the atmosphere to appear perfectly smooth, we decided to use fixed sampling along the lightning rather than Monte Carlo integration for this portion of the rendering. This caused the noise in the atmosphere to be extremely low, at the cost of a small bias.

To speed the volume integration up for the homogeneous low-density atmospheric medium, we used an approximation to the volume rendering equation and derived a closed-form expression for the contribution of a lightning segment to the glow along a ray. This saved us the expense of marching along each ray through the expansive atmospheric volume. The mathematics of the optimization are described in this brief document (PDF).

The lightning's reflection through the clouds was accomplished through a photon map, as described above; we used uniform random sampling of the lightning to generate photon initial positions, and traced their paths through the clouds to generate the photon map. Diffuse shading calculations integrated the lightning uniformly by arc length.

Our code only supports these lights in the form of discrete line segments, but our technique is general and may easily be applied to an arbitrary 1-manifold with boundary. The linear light sources can also define color and brightness as a function on the path. An useful and relatively simple optimization to consider for the future is importance sampling the lightning's geometry when performing diffuse shading calculations. This could be accomplished by using the combined brightness and projected angle of a lightning segment as a probability distribution function.

Boat

Since our project primarly focused on lightning, we decided to use a model from a standard model library instead of modeling our own. Later, we realized the need for more complex lighting for the boat, so we added a latern to the model of the boat. We model the latern as a short segment of lightning with a differenet color than the lightning itself. In the movie, the boat and lantern rock back and forth. The boat uses a procedural Perlin noise texture for the sail, since we wanted to avoid the use of any external textures for our project. Diffuse shading and soft shadows are done by integrating the light sources by arc length, using Monte Carlo sampling.

Grid Computing

To speed up our test cycle, we implemented a simple network job distribution system. The program breaks the image down into one-pixel-wide vertical strips, and farms them out to participating cluster nodes. The overhead of this level of granularity is low, since each cluster node only loads the data component and performs preprocessing steps once per complete image render, and henceforth is available to render any number of strips sequentially. This approach allowed us to render the scene in a quasi-random order, and to display the results as they arrived, rather than waiting for the entire image to finish. In this way, we were often able to cancel bad renders after seconds rather than hours. For the last few days, we assembled a heterogenous cluster of the various computers we had access to (not including the public Stanford labs of course, since we knew everyone in the class needed those!). We managed to put together about 18GHz of processing power to render our final images!

The final images were rendered at 3600 by 2700 pixels with 100 shadow rays per eye ray, and then resampled down to 1280 by 960 to reduce aliasing. The close-up image of the boat with the purple lightning took about 8 hours of rendering time, and the distant views took about 1 hour each.

References

1. Jensen, Henrik W.: "Realistic Image Synthesis Using Photon Mapping." AK Peters, 2001.
2. Williams, Peter L.: "A Volume Density Optical Model." ACM Press, New York, 1992.
3. Ebert, David S.: "Procedural Volumetric Cloud Modeling, Animation, and Real-time Techniques."
4. Dobashi, Y. et al: "Efficient Rendering of Lightning taking into Account Scattering Effects due to Clouds and Atmospheric Particles."
5. Musgrave, F. Kenton: "Quasi-Analytic Error-Bounded Ray Tracing of Procedural Height Fields."
6. Finch, M.: "Effective Water Simulation from Physical Models," in GPU Gems. Addison-Wesley, Boston, 2004.
7. Strauss, Walter A.: "Partial Differential Equations, An Introduction." John Wiley & Sons, Inc., New York, 1992.
